Description
The Heat Lamp Bulb R125 is a specialized infrared heating bulb designed for veterinary applications. It emits infrared radiation to provide warmth to animals, making it ideal for use in livestock farming, veterinary clinics, and pet care settings. The bulb is commonly used to maintain body temperature for newborn animals, provide supplemental heat in animal enclosures, and support the recovery of sick or injured animals. Its robust design and high heat output make it suitable for continuous use in demanding environments.● Color Temperature(CCT) Warm Red
● Lamp Body Material Glass
● Lifespan (hours) 5000
● Input Voltage(V) AC 110V/220V ( ± 10%)
| ELECTRICAL DATA | NOMINAL VALUE | MIN | MAX | |
| Lamp rated wattage(W) | 150 | 144 | 255 | |
| Lamp operating voltage(V) | 240 | |||
| PHOTOMETRIC DATE | NOMINAL VALUE | MIN | MAX | |
| Colour temperature(K) | 1100 | 1000 | 1200 | |
| Lumens output(Lm) | 250 | 150 | 300 | |
| OPERATING CONDITIONS | ||||
| Switching cycle | 23hrs ON,1hrs Off | |||
| Rated average life (h) | 5000 | |||
| Burning position | Universal | |||
| DIMENSIONS | NOMINAL VALUE | MIN | MAX | |
| DIM (mm) | 125 | 123 | 127 | |
| MOL (mm) | 172 | 175 | 178 | |
| Type description | colour | Numerator quntity pack | Net weight | Gross weight |
| IR250W/R125/C/E27 | RED | 24pcs | 2.5Kg | 4.5Kg |
| Safety requirements | ||||
| Torsion between base and bulb | ||||
| Unused lamps:Min | 3N.M | |||
| Afte heating lamp:Min | 2.5N.M | |||
| Instant Voltage impact(at 115% nominal supply volage)[S]: | Min.1 |
● Heat Lamp Bulb R125: The main product, available in various wattages (e.g., 150W, 250W) to suit different heating needs.
● Protective Packaging: The bulb is securely wrapped in foam or placed in a cardboard insert to prevent breakage during transit.
● User Manual: Provides instructions on installation, usage, safety precautions, and maintenance.
● Warranty Information: Details the warranty period and conditions for the bulb.
● Safety Warnings: Highlights potential hazards, such as the risk of burns or fire if the bulb is used improperly.
● Optional Accessories: Some packages may include a porcelain socket (commonly E27 base), a clamp or stand for mounting the bulb, or a protective guard to prevent accidental contact with the hot bulb.
● Reflector (Optional): Some models may include a built-in or separate reflector to direct heat more efficiently.
