Description
LED Apnea Monitor for animal use is a breathing monitoring device specially designed for animals. It is mainly used to monitor the breathing status of animals in real time and issue an alarm when apnea or abnormality is detected.● Large-capacity battery,long working time for 40 hours;
● Built-in Lithium battery,Type-Cinterface charging;
● LED digital tube displays respiratory rate and alarm;
● Available to measure respiratory rate;
● Apnea alarm,Exceed-limit alarm;
● Apnea with Audible alarm;
● Respiratory rhythm sound;
● Automatic wake up breathing,automatic shutdown without breathing detection.
| Physical Specifications | |
| Size | ·68.7mm(h)×62.85mm(w)×24.2mm(d) ·(2.7in(h)×2.47in(w)×0.95in(d)) |
| Weight | 30g |
| Power Supply | |
| External Power | 5V DC,0.4A,Type-C |
| Battery Specifications | |
| Battery capacity | 3.7V/350mAh |
| Operating Time | Operating Time≥40hours |
| Product Configuration | |
| Respiratory Rate,Apnea Alarm,Li-On rechargeable Animals type:cat,dog,horse etc. | |
| Environment Specification | |
| Temperature | 0℃~40℃ |
| Humidity | 15%～80%,non-condensing |
| Environment Specification | |
| Accuracy | ±2rpm |
| Measurement Range | 0~120rpm |
| Alarm Limits | >50rpm or<5rpm |
| Apnea Alarm | 20s |
| Volume | >70dB |
| Display | |
| Display | 3-segment white LED |
● Apnea Monitor Unit:
● The main device with an LED display for monitoring respiratory status, equipped with features like alarms for apneic episodes.
● Electrodes or Sensor Belt:
● Sensors (such as adhesive electrodes or a sensor belt) for attaching to the patient (e.g., infant or animal) to detect respiratory movements or signals.
● A power adapter or batteries (e.g., rechargeable lithium batteries) to power the monitor.
● Mounting or Carrying Accessories:
● Optional accessories like wall mounts, clips, or carrying cases for convenient use or transport.
● Cleaning Supplies:
● Wipes or cleaning solutions for maintaining hygiene, especially for electrodes or sensors that come in contact with the skin.
● Optional Accessories:
● Additional electrodes, replacement batteries, or extended alarm modules (if applicable).
