Description
This product is used in various surgical lighting in hospital operating room。It can also be use in medical lighting situations in emergency room.● Normal working conditions
● Temperature:10℃~30℃;
● Relative humidity:≤70%;
● Atmospheric pressure range:860hPa~1060hPa;
● This equipment can not be worked in flammable and explosive gas environment.
● The type of device security: I type equipment;
● Working system: continuous operation;
● Liquid injection protection level: IPXO.
Type | 700 Main lamp | 500 Main lamp |
Diameter of Light Head (mm) | 700 | 500 |
Quantity of LEDS | 80 | 48 |
Illumination (10 Steps Adjustable) | 40~160klx | 40~160klx |
Color rendering index | Ra>95 | Ra>95 |
Color temperature (5 Steps Adjustable) | 3500-5000K | 3500-5000K |
Depth of illumination (mm) | 1000 | 1000 |
Spot diameter | 120-300mm | 120-300mm |
LED Life | >50,000 Hours | >50,000 Hours |
The model of LED | OSRAM GWCS8PM1.CM | OSRAM GWCS8PM1.CM |
UPS | Optional | Optional |
Control Panel | LCD | LCD |
● Rotating arm 1
● Balance arm ondal for 500 head 1
● Assistant lamp (500) 1
● Handle 1
● Manual 1
● Fuse(f2al250v) 2
