Description
Professional Veterinary Digital Radiography (DR) X-ray System is a specialized imaging system designed for veterinary use, offering advanced digital radiography capabilities to diagnose and monitor animal health conditions.● Anode type: Rotating Anode
● Focal Spot value1.0mm/2.0mm
● Revolving speed of anode2800rpm
● Active Area: 17x17Inch(43cm*43cm),Active Pixel: 2912*2912
● Floating Radiography Table,load-bearing:150KG
| Model | INF-32KW-P-A | INF-32KW-P-B |
| Voltage | 220V±22V;50Hz±1Hz | |
| optional:110V±11V 60Hz±1Hz | ||
| Internal Resistance | <05Ω | |
| Power | ≥40KVA | |
| Output power | 32KW | |
| Frequency | 25KHZ | |
| Current | 10～400mA | |
| Voltage | 40～125KV | |
| Anode type | Rotating Anode | |
| Focal Spot value | 1.0mm/2.0mm | |
| Maximum voltage | 125KV | |
| Revolving speed of anode | 2800rpm | |
| Inherent filtration | 1.0mmAl | |
| Type | Amorphous Silicon | |
| Active Area | 17x17Inch(43cm*43cm) | |
| Active Pixel | 2912*2912 | |
| Pixel Pitch | 139um | |
| A/D Conversion | 16bits | |
| Touch Screen | NO | YES |
● 32kW High-voltage X-ray Generator One set
● Rotating X-ray Tube One set
● Collimator One set
● 17*17 inch Flat Panel Detector One set
● High-voltage Cables One set
● Grid One sets
● Tube Stand One set
● Four-way Floating Radiography Table One set
● Image Capturing and Processing Software One set
● Computer One set
● 21.5 inch LCD Monitor One set
● Hand Switch One set
● DICOM 3.0 One set
● Manual One set
We specialize in providing high-quality medical devices and solutions for breeding enterprises, pet hospitals and research institutions.
